JAT Ecovario 414AR Servo amplifier, 7.1kW
Part Number: ECOVARIO 414AR-BJ-000-000
Technical specifications
| DC supply voltage | 60 VDC |
| DC link voltage | 60 VDC |
| Number of axes | 2 |
| Power category | 1.4 kW |
| Max. output current | 14 A |
The ECOVARIO® 114D is a compact 2-axes servo amplifier and has various interfaces, such as EtherCAT, CANopen, PROFIBUS, PROFINET, RS232, RS485 or Ethernet. 2-phase and 3-phase brushless synchronous motors and synchronous linear motors, EC motors and stepper motors can be controlled via torque/force, speed and position. The power supply 24 … 70 VDC.
Prices indicated are for low order quantities. In most cases we can offer significant reductions when purchased in volume, so please contact us if you have such a requirement and we will prepare a special quote.
